Screed Edge Protection: Preventing Construction Damage

A freshly laid screed can look perfect when the laying team leaves site, but by the time the floor finish goes down weeks or months later, the edges at doorways, day joints, and exposed perimeters have been chipped, crumbled, and damaged by construction traffic. It's one of the most preventable problems in screeding — and one of the most commonly neglected.

Why Screed Edges Are Vulnerable

Screed edges at doorways, thresholds, and construction joints are the weakest points on any screeded floor. Unlike the main body of the screed, which is supported on all sides, the edge has one face exposed. Foot traffic, wheeled barrows, scaffold wheels, and even material deliveries all concentrate their force on these exposed edges. A screed that easily withstands foot traffic across its surface can have its edges crumbled by a single wheelbarrow crossing an unprotected threshold.

The problem is compounded by the fact that screeding often happens early in the construction programme. Months of building activity follow — plumbing, electrical, plastering, joinery, painting — and every one of those trades crosses the screeded areas. Without protection, the accumulated damage can be significant.

Simple Protection Methods

Edge protection doesn't need to be elaborate or expensive. Simple, practical measures applied immediately after the screed has set are highly effective.

Timber Battens

A strip of 50x25mm softwood timber fixed along exposed screed edges at doorways and day joints is the most common protection method. The timber takes the impact from traffic instead of the screed edge. It can be temporarily fixed with masonry nails or adhesive and removed when the floor finish is ready to be applied.

Chipboard or Plywood Strips

Wider strips of 18mm chipboard or plywood placed along traffic routes and at doorways spread the load over a larger area. This is particularly useful in corridors and main circulation routes where wheeled traffic is frequent. Tape the edges down or fix with temporary screws to prevent them shifting.

Proprietary Edge Strips

For permanent protection at thresholds and movement joints, metal or PVC edge strips can be cast into the screed surface during laying. These provide a hard, impact-resistant arris that protects the screed edge for the life of the floor. They're particularly useful at doorways between rooms with different floor finishes or levels.

Protecting the Main Screed Area

Edge protection is part of a wider site protection strategy. The main body of the screed also needs consideration, particularly on busy construction sites. Heavy point loads — scaffold base plates, trestles, material stacks — should always be placed on spreader boards to distribute the weight. If scaffold is to be erected on a screeded floor, ensure the base plates sit on plywood pads at least 450mm x 450mm.

For high-traffic routes, continuous protection boarding is the most effective approach. Lay 18mm plywood or protection board across the entire traffic path, overlapping at joints, and secure in place. Yes, it costs money — but significantly less than the screed repair or levelling compound needed to correct traffic damage.

Timing Matters

Protection should be installed as soon as the screed can accept it without surface damage — typically 24-48 hours after laying for traditional screeds, or as soon as the surface is hard enough to walk on. Leaving protection until damage has already occurred defeats the purpose. The best approach is to plan the protection requirements before screeding begins and have the materials ready on site.
